Key Information
- Rotation: Clockwise (looking from shaft end)
- 7/8” Diameter 13T SAE B splined shaft
- SAE B 2 hole mounting flange
- Front Pump displacement: 37 cc/rev (37L/Min per 1000 rpm)
- Rear Pump displacement: 16 cc/rev (16L/Min per 1000 rpm)
- 1 7/8" UNF threaded inlet
- Front pump 1 1/16" UNF threaded outlet
- Rear pump 7/8" UNF threaded outlet
Replaces the following JCB part numbers
Weight
Machine Fitment
- TOW HITCH HYDRAULIC CIRCUIT 527-55 TIER 3 9812/7560
- TOW HITCH HYDRAULIC CIRCUIT 524-50 TIER 3 9812/7560
- TOW HITCH MANUAL CIRCUIT 524-50 TIER 3 9812/7560
- TOW HITCH MANUAL CIRCUIT 527-55 TIER 3 9812/7560
- PUMP MAIN HYDRAULIC 527-55 TIER 3 9812/7560
- PUMP MAIN HYDRAULIC 524-50 TIER 3 9812/7560
- PUMP,GEAR 527-55 TIER 3 9812/7560
- PUMP,GEAR 524-50 TIER 3 9812/7560
- PUMP/MOTOR INSTALLATION ASSEMBLIES PUMPS GEAR 2 STAGE, 37 AND 16CC, 524-50, 527-55 527-55 4WS 9822/0425
- PUMP/MOTOR INSTALLATION ASSEMBLIES PUMPS GEAR 2 STAGE, 37 AND 16CC, 524-50, 527-55 524-50 4WS 9822/0425
